ATV FERTILISER SPREADER YOILP-SPREADER 12V

12 VOLT ATV FERTILISER SPREADER - 60 LITRE

GENARAL:

This spreader has been designed and manufactured solely for use behind ride on mowers for the application of granular fertilizers. It may also be used behind other vehicles where the maximum speed is kept below 10km/hr.
HOPPER:
60 litre UV stable polyethylene.
NOTE: Volumes of fertilizer will vary according to the type and density of fertilizer used.60 litre is the volumetric capacity of the hopper.
CONTROLS:
On/off power switch on motor to control spinner plate.
Lever manual control to start and stop flow from the hopper as well as control the rate of fertilizer flow.

MOTOR:
12 Volt DC,14 Amp, 850rpm 3.9m Electric cable with crocodile clips.-Negative Black crocodile clip with Blue wire and +Positive
Red crocodile clip with brown wire.
NOTE: If connected to the battery back to front then the motor will spin the wrong way
Anti-clockwise when viewed from the top of the motor is the correct direction.
WHEELS:
380mm Diameter, 95mm wide, suits 1" (25.4mm) axle

SPREADING WIDTH:
10, The maximum throw will vary depending on the type of fertilizers being used

DIMENSIONS:

Height: 1040 mm.

Width: 760 mm

Length: 1140 mm

Dry Weight: 18 kg
