  • DC DIESEL PUMP 1224C 12V/1224D 24V

DC DIESEL PUMP 1224C 12V/1224D 24V

1224C 12V

1224D 24V

• 40L/MIN

• 140W

• 2800RPM

• 3/4”

• 22A(12V),12A(24V)

• 3.5KGS

• 4/CTN 19/18KGS 36X23X32CM

0086 133 0661 7111 Contact Us
  • Description
  • Additional Information
  • Contact Us

  • Technical specifications

    • Cast iron pump body finished with anti-corrosion paint.

    • Vane pump with sintered steel rotor and acetal resin vanes.

    • By-pass valve incorporated in the pump body.

    • Direct current brush motor with permanent magnet stator.

    • Motor protection grade IP55.

    • Used in intermittent service with 30-minute work cycles.

    DC fuel transfer pumps

    Displacement, self-priming, rotary electric vane pumps for the transfer of diesel fuel equipped with by-pass valve. Powerful,dependable and economical, they are available with 12 and 24-volt direct current motors.
