DC DIESEL PUMP 1225C 12V/24V

1225C 12V

1225C 24V

• 50L/MIN (13GPM)

• 260W

• 2600RPM

• 3/4”

• 22A(12V),11A(24V)

• 1.5BAR

• 3.5KGS

• 4/CTN 19/18KGS 36X23X32CM

0086 133 0661 7111 Contact Us

Technical specifications

• Cast iron pump body finished with anti-corrosion paint.

• Vane pump with sintered steel rotor and acetal resin vanes.

• By-pass valve incorporated in the pump body.

• Direct current brush motor with permanent magnet stator.

• Motor protection grade IP55.

• Used in intermittent service with 30-minute work cycles.

DC fuel transfer pumps

Displacement, self-priming, rotary electric vane pumps for the transfer of diesel fuel equipped with by-pass valve. Powerful, dependable and economical, they are available with 12 and 24-volt direct current motors.
