STORAGE TANK EQUIPMENT FV-B-4-W-YE

Fast，safe vapor recovery is easy with this probed hose coupler.Hose shank end bands to a vapor recovery hose and the probe automatically opens the poppet of the vapor check valve when coupled.The coupler comes in threesizes for use with mostvapor check valves and hose configurations.
The poppetted vapor returning to hose coupler design prevents vapor from escaping when disconnected and the probe automatically opens the vapor check valve when connected properly. The design also offers low restrictive vapor passage.
The body and probe are made of heat treated anodized.Aluminum，withBrass cams,stainless steel pins,and thepoppet has a replaceable Buna-N "O" ring.

0086 133 0661 7111 Contact Us

Description
Additional Information
Contact Us

Package:

Net Weight:7.8KG/PC

Gross Weight:8KG/PC

38X32X35 cm³Case of 6PC

Features ＆ Benefits:

•Fits Std 4" TTMA Sump

•Shear section per TTMA,RP84-92 and meets DOT 49 CFR 178.345-8

•Force ratings from TTMA RP86-92

•Shear Groove meets DOT 406 requirements

•Optional External Air Cylinder available

•Available in flanged veraiable

•Seals-viton

•High quality die cast body and component materials, to international standards,are used for durability and performance. •Lightweight aluminium construction for increased payloads.

•High lift poppet for maximum flow.

•External shear groove meets TTMA and NTTC DOT 406 to limit product spillage in the event of an accident.

•Closure by self-centring plunger and durable compression spring.

•Brass cam with bearing boot on plunger stem for smooth operation and exended life.

•Double O-ring seals on camshaft for improved sealing and ease of maintenance.
