  • DC DIESEL PUMP 1225B 12V/24V

DC DIESEL PUMP 1225B 12V/24V

1225B 12V

1225B 24V

• 50L/MIN (13GPM )

• 260W

• 2600RPM

• 1”

• 24A(12V),17A(24V)

• 1.5BAR

• 3.5KGS



0086 133 0661 7111 Contact Us
  • Description
  • Additional Information
  • Contact Us

  • Technical specifications

    • Cast iron pump body finished with anti-corrosion paint.

    • Vane pump with sintered steel rotor and acetal resin vanes.

    • By-pass valve incorporated in the pump body.

    • Direct current brush motor with permanent magnet stator.

    • Motor protection grade IP55.

    • Used in intermittent service with 30-minute work cycles.

    DC fuel transfer pumps

    Displacement, self-priming, rotary electric vane pumps for the transfer of diesel fuel equipped with by-pass valve. Powerful, dependable and economical, they are available with 12 and 24-volt direct current motors.
